DA7000 SERIES GENERATORS • OPERATION AND PARTS MANUAL — REV. #5 (01/20/11) — PAGE 139
KUBOTA Z482-EB/E2B/E3B ENGINE — DYNAMO ASSY.
DYNAMO ASSY.
NO.
PART NO.
PART NAME
QTY.
REMARKS
010
1753164010
DYNAMO ASSY. , Z482-EB ...........1 ........................ INCLUDES ITEMS W/%
010
1753164012
DYNAMO ASSY. , Z482-E2B/E3B ..1 ........................ INCLUDES ITEMS W/#
020
1553164122
COMP. FLYWHEEL, Z482-EB ........1 ........................ INCLUDES ITEMS W/+
020 1553264120 COMP. FLYWHEEL, Z482-E2B/E3B .1 ........................ INCLUDES ITEMS W/<
030%#+< 1553164110
PULLEY
1
040%+
1553164040
FLYWHEEL ....................................1 ........................ Z482-EB
040#<
1553264040
FLYWHEEL ....................................1 ........................ Z482-E2B AND Z482-E3B
050%+
6C04082860
COLLAR.........................................1 ........................ Z482-EB
050#+<
1553164140
COLLAR.........................................1 ........................ Z482-E2B AND Z482-E3B
060%#+< 1553174180
BEARING, BALL
2
070%+
1553174140
SHAFT, FAN ...................................1 ........................ Z482-EB
070#<
1553274140
SHAFT, FAN ...................................1 ........................ Z482-E2B AND Z482-E3B
080%
1553164363
COMP. STATOR, Z482-EB .............1 ........................ INCLUDES ITEMS W/>
080#
1553264360
COMP. STATOR, Z482-E2B/E3B ...1 ........................ INCLUDES ITEMS W/$
090%#>$ 1526193010
SCREW, ROUND HD.
2
100%#>$ 1553164292
STATOR
1
110%> 1553164072 PLATE
............................................1
........................ Z482-EB
110#$
1553264070
PLATE ............................................1 ........................ Z482-E2B AND Z482-E3B
120%#>$ 1553174180
BEARING, BALL
1
130%#>$ 1553193010
SCREW, ROUND HD.
1
140%#>$ 1553164190
CLAMP, CORD
1
150%# 1526164150 COLLAR
1
160%
1526192030
NUT................................................1 ........................ Z482-EB AND Z482-E3B
160# 0277160100 NUT,
FLANGE
................................1
........................ Z482-E2B
170%
1526194070
WASHER, LOCK............................1 ........................ Z482-EB AND Z482-E3B
180%
1526194020
WASHER, FLAT .............................1 ........................ Z482-EB AND Z482-E3B
