DA7000 SERIES GENERATORS • OPERATION AND PARTS MANUAL — REV. #5 (01/20/11) — PAGE 69
ELECTRIC PARTS ASSY.
NO.
PART NO.
PART NAME
QTY.
REMARKS
1
A5262500203
BRACKET ELECTRIC PARTS
1
2
0016906016
HEX HEAD BOLT
4
3
0601842463
RESISTOR, 30W 10 OHM
1
4 0027104012 MACHINE
SCREW
2
5 0601823204 RECTIFIER,
S5VB60
2
6 0027103020 MACHINE
SCREW
2
7 0601823754 RELAY
1
8 0027105016 MACHINE
SCREW
1
9 1569465990 LAMP
TIMER
.....................................................1................REPLACES
0602201273
10
0017105016
HEX HEAD BOLT
1
11
1747260604
EMERGENCY UNIT ..........................................1................REPLACES 0602200475
12
0017105025
HEX HEAD BOLT
4
13 0601815731 TERMINAL
BOARD
1
14 0601815759 TERMINAL
BOARD
1
15 0027105020 MACHINE
SCREW
4
16 8701899004 FUSE
BOX
1
16A 0601806642
FUSE,
5A
4
16B 0601806643
FUSE,
15A
2
16C 0601806644
FUSE,
30A
2
17 0027105020 MACHINE
SCREW
2
18 0601827350 CONTROL
UNIT
1
19 0027104010 MACHINE
SCREW
2
20 1584464600 REGULATOR
.....................................................1................REPLACES
1584464601
21
0017105025
HEX HEAD BOLT
2
22
16226361032
ROTARY SOLENOID .........................................1................REPLACES 1620150404
23 1992636004 ARM
SOLENOID
1
24 0050403020 SPRING
PIN
1
25
16226361032
HEX HEAD BOLT ...............................................1................REPLACES 0010106025
25A
0030006000
HEX NUT ...........................................................1................REPLACES 0030006000
26 0207206000 HEX
NUT
2
27 D235630004 GOVERNOR
ROD
1
28
031108160
WASHER, FLAT .................................................1................REPLACES 0041608000
29 0605010503 SNAP
PIN
1
30 0042806000 WASHER,
FLAT
1
31
505015300
SNAP PIN ..........................................................1................REPLACES 0605010502
32
0010108050
HEX HEAD BOLT
1
33A
020108060
HEX NUT ...........................................................1................REPLACES 0207008000
33 0601806640 FUSE,
65A
1
34 A5485500004 GUIDE
1
35
0016906016
HEX HEAD BOLT
2
