DA7000 SERIES GENERATORS • OPERATION AND PARTS MANUAL — REV. #5 (01/20/11) — PAGE 143
KUBOTA Z482-EB/E2B/E3B ENGINE — STARTER COMP. ASSY.
STARTER COMPONENTS ASSY.
NO. PART NO. PART NAME QTY. REMARKS
010 1983763010 STARTER ASSY. ................................................1................INCLUDES ITEMS W/@
020@ 1983763050 LEVER, DRIVE 1
030@ 1585263020 SWITCH, MAGNETIC 1
040@ 1983763030 FRAME, DRIVE END .........................................1................INCLUDES ITEMS W/#
050@# 1585263240 BUSH 1
060@ 1983763150 STOPPER 1
070@ 1983763040 CLUTCH, OVER RUNNING 1
080@ 1983763320 BOLT 2
090@ 1983763070 ARMATURE 1
100@ 1585263410 WASHER, ADJUSTING 1
110@ 1983763080 YOKE ASSY. .....................................................1................INCLUDES ITEMS W/%
120@% 1585263360 BRUSH 2
130@ 1585263380 HOLDER, BRUSH ASSY. ...................................1................INCLUDES ITEMS W/+
140@+ 1585263390 SPRING, BRUSH 3
150@+ 1585263370 BRUSH 1
160@ 1983763200 FRAME, END .....................................................1................INCLUDES ITEM W/$
170@$ 1585263250 BUSH 1
180@ 1585293310 SCREW, PAN-HEAD 1
