Basic Guidelines on Using the SMX-M8xx Series USB2.0 Cameras
67
Appendix 4
B
ASIC
G
UIDELINES
ON
U
SING
THE
SMX-M8
XX
S
ERIES
USB2.0 C
AMERAS
Introduction
The SMX-M8xx Series Cameras - are megapixel CMOS cameras with USB2.0 interface.
The SMX-M8xx Series Cameras are available in three modifications:
●
SMX-M81M (1.3 Megapixel, monochrome)
●
SMX-M82C (2 Megapixel, color)
●
SMX-M83C (3 Megapixel, color)
All the SMX-M8xx cameras feature small size and C/CS-mount form factor.
The SMX-M8xx cameras are supplied with C-mount adapter and/or C-mount adapter
with IR-cut filter for converting CS-mount to C-mount.
Camera Kit
The SMX-M8xx Camera Kit includes:
●
SMX-M8xx Series Camera:
●
The SMX-M8xx Series USB2.0 Cameras Software Package which is available for down-
loading via the provided URL
●
USB A to USB mini-B cable (optional):
