Introduction: Camera Specifications
6 SMX-M8xx Series USB2.0 Camera User Guide
Camera Specifications
Table 1-1 Output Video and Camera Control Characteristics
SMX-M81M Camera SMX-M82C Camera SMX-M83C Camera
Maximum
resolutions of
output window 1280x1024, full
resolution mode 1600 x 1200, full
resolution mode 2048 x 1536, full
resolution mode
Max Frame rate at
resolution
(24MHz)
*
15 fps at 1280 x 1024
24 fps at 1024 x 768
37 fps at 800 x 600
40 fps at 768 x 576
54.7 fps at 640 x 480
89.5 fps at 400 x 400
166 fps at 320x240 10 fps at 1600x1200
14 fps at 1280 x 1024
22.7 fps at 1024 x 768
34.6 fps at 800 x 600
37 fps at 768 x 576
50 fps at 640 x 480
79.6 fps at 400 x 400
145 fps at 320x240 6 fps at 2048x1536
10 fps at 1600x1200
13.9 fps at 1280 x 1024
21.9 fps at 1024 x 768
33 fps at 800 x 600
35.7 fps at 768 x 576
48 fps at 640 x 480
75 fps at 400 x 400
138.5 fps at 320x240
Output bit per pixel Selectable, 8 bits or 10
bits
Selectable, 8 bits or 10
bits Selectable, 8 bits or 10
bits
Lookup table Software, converts 10
bits of imaging chip's
ADC to 8 bits of output
for user selected 8 bits
mode Software, converts 10
bits of imaging chip's
ADC to 8 bits of output
for user selected 8 bits
mode Software, converts 10
bits of imaging chip's
ADC to 8 bits of output
for user selected 8 bits
mode
Pixel rates 12 MHz, 24 MHz 12 MHz, 24 MHz 12 MHz, 24 MHz
Exposure range 0.06 - 65.7 ms (24 MHz,
1280 x 1024, 1:1); More
than 2 sec with fps
decrease 0.07 - 96.91 ms (24
MHz, 1600 x 1024, 1:1);
More than 2.5 sec with
fps decrease 0.09 - 156.92 ms (24
MHz, 2048 x 1536, 1:1);
More than 200 sec
with fps decrease
Pixel Gain Control Programmable
(Hardware): 48 gain
levels from 1 to 15 Programmable
(Hardware): 48 gain
levels from 1 to 15
Gain controls for R, G,
B: 48 gain levels from 1
to 15 Programmable
(Hardware):161 gain
levels from 1 to 128
Gain controls for R, G,
B: 161 gain levels from
1 to 128
