Camera Device Settings: Output Bits per Pixel Control
41
SMX-M8xx Series USB2.0 Camera User Guide
1.
Click the Frame Rate… button to open the Frame Rate Control window
2.
Click the Set Maximum button to get the maximal value or click the Set Default
button to get the default value
3.
Close the window
Note:
When changing frame rate value manually, a warning message may appear. Usually it appears when the
entered value is lower than it is allowed. In this case, follow the instructions in the warning message (
4 Warning message of the Frame Rate Control window
)
Figure 7-4 Warning message of the Frame Rate Control window
Output Bits per Pixel Control
10 bit - enables the software to transmit 10 bit images from the camera as opposed to
regular 8 bit.
Median Filter
Median filter - turns on pixel averaging. The brightness of every single pixel becomes
affected by the brightness of its neighbor pixels and the whole image becomes
smoother.
Limit Gain
Limit Gain 10 - limits maximal value of Gain to 10.
