Modulation Mode /
Payload Type
Maximum
Aggregate
Data Rate
10 11
(Mbit/s)
Threshold
Value
(dBm)
Output
Power
(dBm)
Maximum Link
Loss
(dB)
256QAM 0.81 dual 300.2 -59.1 +18 124.1
64QAM 0.92 dual 252.9 -62.0 +18 127.0
64QAM 0.75 dual 206.7 -68.1 +18 133.1
16QAM 0.87 dual 160.8 -71.0 +20 138.0
16QAM 0.63 dual 115.6 -75.2 +22 144.2
16QAM 0.63 single 57.8 -79.3 +22 148.3
QPSK 0.87 single 40.2 -81.6 +23 151.6
QPSK 0.63 single 28.9 -84.6 +24 155.6
BPSK 0.63 single 14.4 -88.1 +25 160.1
256QAM 0.81 single 150.1 -64.0 +18 129.0
64QAM 0.92 single 126.4 -65.9 +18 130.9
64QAM 0.75 single 103.3 -71.7 +18 136.7
16QAM 0.87 single 80.4 -74.8 +20 141.8
Table 8 - 5.8GHz Aggregate Ethernet throughput rate versus maximum link loss
The full calculation is relatively complicated and thus Motorola has supplied a link estimator
that calculates the radio propagation and reliability of NLOS links using the PTP 600 Series
Bridge equipment.
A more detailed discussion on data rates can be found in Section 16.
10
Aggregate data rate in 40:40 mode for a 1km link length
11
Data rates for PTP 600 Series Bridge Lite product are 50% of the figures shown
