qSide and Curtain Air Bag System Components
(1)
(3)
(4)
(2)
(5)
(2)
(4)
(1) Air bag/front seat belt pretensioner system warning light (page 2-54)
(2) Side and curtain inflators and air bags
(3) Front seats
(4) Side crash sensor
(5) Crash sensors and diagnostic module (SAS unit)
Essential Safety Equipment
SRS Air Bags
2-45
