NOTE
l If the halogen bulb is accidentally touched,
it should be cleaned with rubbing alcohol
before being used.
l Use the protective cover and carton for the
replacement bulb to dispose of the old bulb
promptly and out of the reach of children.
l When reinstalling the sealing cover, make
sure
faces up.
Replacing a fog light bulbs
í
1. Remove the three screws under the
mudguard by turning them
counterclockwise, and partially open
the mudguard.
2. Turn the socket and bulb assembly
counterclockwise, and carefully pull it
rearward.
3. Disconnect the socket and bulb
assembly from the electrical connector
by pressing the tab on the connector
with your finger and pulling it.
4. Install the new socket and bulb
assembly in the reverse order of
removal.
NOTE
l If the halogen bulb is accidentally touched,
it should be cleaned with rubbing alcohol
before being used.
l Use the protective cover and carton for the
replacement bulb to dispose of the old bulb
promptly and out of the reach of children.
Maintenance and Care
Owner Maintenance
8-39 í
Some models.
