3. Turn the socket and bulb assembly
counterclockwise and remove it.
4. Disconnect the bulb from the socket.
Rear turn signal
lights
Reverse lights
Brake lights/Tail
lights Bulb type
Reverse lights
Rear turn signal
lights
LED type
NOTE
The LED-type bulbs for the brake lights/
taillights/Rear side-marker lights cannot be
replaced by the customer. For bulb
replacement, consult an Authorized Mazda
Dealer.
5. Install the new bulb in the reverse order
of removal.
High-mount brake light
Due to the complexity and difficulty of
the procedure, the LED bulbs should be
replaced by an Authorized Mazda Dealer.
License plate lights
1. Remove the liftgate cover.
2. Pull the socket and bulb assembly and
remove it.
3. Disconnect the bulb from the socket.
4. Install the new bulb in the reverse order
of removal.
Maintenance and Care
Owner Maintenance
8-41
