qControl Switches
AUTO switch
Without rear ventilation system
With rear ventilation system
By pressing the AUTO switch the
following functions will be automatically
controlled in accordance with the set
temperature:
l Airflow temperature
l Amount of airflow
l Selection of airflow mode
l Outside/Recirculated air selection
l Air conditioner operation
NOTE
AUTO switch indicator light
l When on, it indicates AUTO operation, and
the system will function automatically.
l When off, it indicates the operation of other
switches such as the mode selector switch,
fan control dial, A/C switch and windshield
defroster switch. Other functions will
continue to operate automatically.
OFF switch
Without rear ventilation system
With rear ventilation system
Pressing the OFF switch shuts off the
climate control system.
Interior Comfort
Climate Control System
6-11
