LT12 SerieS LigHT TOWer • parTS manuaL — rev. #17 (06/03/11) — page 53
GEnEratOr assY. (s/n 902149 anD aBOvE)
nO. parT nO. parT name QTY. remarkS
1% 9903905068 REAR SEAL 1
2% 9903905069 LIFTING HOOK 2
3% 9909510155 PG21 CABLE GLAND 1
4% 9909510195 PG21 NUT 1
5% GELT3100ROD COVER STAY BOLT AND NUT 4
6% 6102204175 NON-DRIVE END BRACKET 1
7% GELT3ENCBAND ENCLOSING BAND 1
8% GELT3100STATOR60 WOUND STATOR AND FRAME 1
9% 6102208192 DRIVE END BRACKET 1
10% 6102208193 INTERCHANGEABLE FLANGE 1
11% 6110611508 RING SPACER 1
12% GEECO3DISC65 FLEXIBLE DISC 1
13% 7502223039 FAN 1
15% GELT3100ROTOR60 ROTOR ASSY 1
16% 9910359005 DIODES 2
17% 7501001015 HEAT SINK, ROTATING DIODE BRIDGE 2
18% 9909527011 SUPPORT, ROTATING DIODE BRIDGE 1
19% 9900905055 REAR BEARING 6205-2RS 1
20 29895 GENERATOR LT3 ..........................................1 ......... INCLUDES ITEMS W/%
21% 29895SCREW COVER SCREWS, SET OF 3 1
