LT12 SerieS LigHT TOWer • parTS manuaL — rev. #17 (06/03/11) — page 45
GEnEratOr/EnGInE MOuntInG assY. (PErKIns)
nO. parT nO. parT name QTY. remarkS
2 0161 C WASHER, LOCK 5/16 MED 6
3 0655 SCREW, HHC 5/16-18 x .75 6
4 0166 A WASHER, LOCK 3/8 MED 8
5 1023 SCREW, HHC 3.8-16 x 1-1/4 GR 5 8
6 1023 SCREW, HHC 3/8-16 X 1 1/4 GR 5 1
9 29684 SUPPORT, MECC ALTE GENERATOR 1
10 29649 MOUNT, VIBRATION KORFUND RB1-200 4
11 19470 WASHER, FLAT 5/16 USS 2
12 9182 SCREW, HHC M8-1.25 X 45MM PLATED 2
13 4001 WASHER, FLAT USS 3/8 PLD 6
14 10133 NUT, NYLOC 3/8-16 3
