LT12 SerieS LigHT TOWer • parTS manuaL — rev. #17 (06/03/11) — page 35
cOntrOl PanEl/Ballast assY. (s/n 904385 anD aBOvE)
nO. parT nO. parT name QTY. remarkS
1 0166 A WASHER, LOCK, 3/8 MED. 1
2 0205 SCREW, HHC 3/8-16 X 1 PLATED 1
3 0655 SCREW, HHC 5/16-18 1
4 1876 NUT, HEX FINISH 3/8-16 1
5 2574 GROMMET, 5/16" ID 7/16" OD 1
6 8133 SCREW, PHP 10-32 X 3/4 12
7 10019 NUT, NYLOC 10-32 6
8 12277 CLAMP, HOSE WORM 1-9/16 TO 2 SIZE 32 4
9 49048 SCREW, HHFS 1/4-20 X 3/4 G5 8
10% 19266 NUT, BLIND 1/4-20 X 10 GA 8
11 19297 LIGHT, PETERSON MFG V438 1
12 19968 TERMINAL BLOCK ( DC 70014 ) 2
13 29071 CONNECTOR, QUICK SCREW TERMINAL 4
14 29276 RECEPTACLE, 4PRG LOCKING 30A, 120/250V 1
15 29343 DUPLEX OUTLET, 15A 120V GFCI UL CSA 1
16 29603 SWITCH, MOMENTARY 1
18 29646 COVER, 110 GFI OUTLET 1
19 29647 COVER, 220 OUTLET 1
20 29655 FITTING, STRAIN RELIEF HEYCO 3234 2
21 29656 LOCKNUT, NYLON 2
22 29712 BOLT, CARRIAGE 1/4-20 X 3/4 8
23 29796 CLAMP, CUSHIONED LOOP, 1-3/4 DIA X1 1
24 29797 NUT, BLIND 10-32 X 02/.13 GRIP 6
25 W29109 NUT, WING 3/8-16 1
28 49046 HARNESS, LT-12 CONTROL (AC) 1
29 49047 WIRING KIT, LT-12 1
31 49070 NUT, FLANGED 1/4-20 SERATED PLTD 8
32 49071 NUT, FLANGED 5/16-18 SERATED PLTD 1
33 29865 SNAP SWITCH PLATE ASSY. ..........................................1 ........... INCLUDES ITEMS W/%
34% 29864 SNAP FIT SWITCH INSERT 1
35% 29848 CIRCUIT BREAKER, 2 POLE, 30A SNAP FIT ................1 ........... S/N 902626 AND ABOVE
36% 29847 CIRCUIT BREAKER, 1 POLE, 15A SNAP FIT 5
39 19229 BALLAST AND CAPACITOR, M47 ...................................4 ........... INCLUDES ITEMS W/@
40@ M1000120AC5M BALLAST/TRANSFORMER 60 HZ 4
41@ 19598 BALLAST CAPACITOR 24 µF @480 V 4
42 29719 SCREW HHC M5-.8 X 8MM PLATED, 8.8 DIN 8
43 29795 BRACKET, DEUTZ CONTROL PANEL 2
44 7245454 CONTROL PANEL, LOMBARDINI 1
45 50404900 KEYS, IGNITION, DOUBLE-SIDED 2
47 50384401 IGNITION SWITCH 1
48 GECAP25MF EXCITATION CAPACITOR 25µF @425V .........................1 ........... S/N 902149 AND ABOVE
