LT12 SerieS LigHT TOWer • parTS manuaL — rev. #17 (06/03/11) — page 21
nO.
parT nO. parT name
QTY.
remarkS
1+
562101
CABLE KEEPER KIT .............................................2 .........INCLUDES ITEM W/@
2@+
NUT
2
3@+
WASHER, LOCK
2
4@+
CABLE CLAMP
1
5@+
CARRIAGE BOLT
2
6+
DRUM ASSY. ..........................................................1 .........SEE NOTICE BELOW
7+
DRUM SPACER .....................................................1 .........SEE NOTICE BELOW
8+
29206
HANDLE ASSY.
1
9+
LOCK NUT 1/2-13..................................................1 .........STD. HDW. PURCHASE LOCALLY
10+
12124S01 COVER ASSY
1
11+
BOLT LOCK ...........................................................1 .........SEE NOTICE BELOW
12+
CAP SCREW 1/2-13 ..............................................1 .........STD. HDW. PURCHASE LOCALLY
13%+
LOCK NUT
2
14+
CAP SCREW 3/8-16 ..............................................1 .........STD. HDW. PURCHASE LOCALLY
15+
1564S01
INPUT SHAFT
1
16+
1563S01
KIT, INPUT SHAFT ................................................1 .........INCLUDES ITEM W/#
17#+
LOCK NUT 1/2-13
3
18#+
SPACER
1
19#+
BUSHING
2
20#+
SHAFT BRAKE DISC
1
21#+
RATCHET GEAR
1
22#+
PINION AND DISC
1
23+
6730S00
RATCHET KIT ........................................................2 ......... INCLUDES ITEMS W/%
24%+
RATCHET SPACER
2
25%+
RATCHET SPRING
2
26%+
RATCHET PAWL
2
27%+
SHOULDER BOLT 5/16-18
2
28+
LOCK NUT 3/8-16..................................................1 .........STD. HDW. PURCHASE LOCALLY
29+
FRAME ..................................................................1 .........SEE NOTICE BELOW
33+
1558S00
FRICTION DISC KIT
2
34+
FRAME SPACER ...................................................1 .........SEE NOTICE BELOW
35
19976
HAND WINCH 1200 LBS. COMPLETE ASSY. .......1 .........INCLUDES ITEMS W/+
WIncH assY. (FultOn)
NOTICE
Sold only as a complete assembly. Use part number
19976 when ordering.
