LT12 SerieS LigHT TOWer • parTS manuaL — rev. #17 (06/03/11) — page 27
t-Bar assY. (s/n 901682 anD aBOvE)
nO.
parT nO. parT name
QTY.
remarkS
1
10306
SCREW, HHC 1/2-13 X 4 1/2
2
2
13211
WASHER, FLAT 1/2 IN. USS
8
3
10176
NUT, NYLOC 1/2-13
4
4
26560
NUT, LOCKING 3/4 NPT CONDUIT
1
5
19965
CORD GRIP (HUBBELL 07401017)
1
7
11505
CLAMP
1
9
3254
TERMINAL, RING 16-14 3/8 IN.
1
11
06503-026 SCREW, HHC 1/2-13 X 3-1/4 IN.
2
13
29781
TEE-BAR, LIGHT MOUNT, MLT/DLT SPERO
1
14
29168
RECEPTACLE ASSY
4
15
19687
CRIMP, SLEEVE (30-410)
7
16
19688
INSULATOR, SPLICE CAP (2007)
7
18
19945
PLATE, T-BAR WIRING COVER
1
19
19944
GASKET, T BAR
1
20
29046
SCREW, PHPM 10-32 X 3/8 IN. ZINC
7
21
29047
DECAL, HIGH VOLTAGE
1
22
19972
REFLECTOR, RED, PETERSON #B491R
1
