Multiquip Nighthawk Series Dedicated Light Tower LT12D - Manual (Page 33)

LT12 SerieS LigHT TOWer • parTS manuaL — rev. #17 (06/03/11) — page 33
cOntrOl PanEl/Ballast assY. (s/n 904384 anD BElOW)
nO. parT nO. parT name QTY. remarkS
1 15177 SCREW, PAN HEAD 10-32 X 1 4
2 29647 COVER, 220 OUTLET COOPER P/N 1990 1
3 10019 NUT, NYLOC 10-32 9
4 5065 B SCREW, RHM #10-32 x 0.5 5
5 29276 RECEPTACLE, 4PRG LOCKING 30A, 120/250V 1
6 29646 COVER, 110 GFI OUTLET COOPER P/N 2966 1
7 29343 DUPLEX OUTLET, 15A 120V GFCI UL CSA 1
8 1623 SCREW, RHM #10-24 x 0.75 2
9 19968 TERMINAL BLOCK ( DC 70014 ) 1
10 29071 CONNECTOR, QUICK SCREW TERMINAL 3
11 1618 NUT, NYLOC 10-24 2
12 0205 SCREW, HHC 3/8-16 X 1 PLATED 1
13 W29109 NUT, WING 3/8-16 1
14 0166 A WASHER, LOCK, 3/8 MED. 1
15 1876 NUT, HEX FINISH 3/8-16 1
16 29640 HOUR METER, SENDEC RECT FLUSH MOUNT 1
17 19297 LIGHT, PETERSON MFG V438 1
18 19819 SCREW, PHP #6-32 x 0.25 14
19 1450 WASHER, FLAT #6 SAE 14
20 29688 CIRCUIT BREAKER, 120VAC 10A DLT LIGHT 4
21 29376 CIRCUIT BREAKER, 15A, 227 VAC KD-1800 1
22 19223 30 A 277 V CIRCUIT BREAKER 1
23 29603 SWITCH, MOMENTARY OFF COLE HERSEE 9075 1
24 29607 BRACKET, LIGHT SWITCH DLT 1
25 0131 A SCREW, HHC 1/4-20 X 3/4 IN. 2
26 0181 B WASHER, LOCK 1/4 IN. MED 2
27 0948 WASHER, FLAT SAE 1/4 10
28 19266 NUT, BLIND 1/4-20 X 10 GA 32
29 12287 SCREW, THP 1/4-20 X 3/4 SS 8
30@ 19598 BALLAST CAPACITOR 24 µF @480V 4
31 10434 CLAMP, HOSE WORM 1-9/16 TO 2 SIZE 32 4
32 10024 NUT, NYLOC 1/4-20 8
33 29655 FITTING, STRAIN RELIEF HEYCO 3234 3
34 10237 WASHER, EXT. SHKP #10 3
38 100AC CONTROL PANEL, PERKINS ENGINE 1
39 385201161 IGNITION SWITCH W/KEY, PERKINS .........................................1 ............. INCLUDES ITEMS W/%
40 385210060 KEY, IGNITION, PERKINS 1
41 390190030 PLATE, IGNITION SWITCH 1
42 15177 SCREW PHP 10-32 X 1 4
43 12851652 CONTROL PANEL, DEUTZ/LOMBARDINI ENGINE 1
44 12850033 IGNITION SWITCH W/KEY, DEUTZ, SINGLE-SIDED 1
44 50384401 IGNITION SWITCH, DOUBLE-SIDED 1
45 12850033KEY KEY, IGNITION, SINGLE-SIDED 1
45 50404900 KEY, IGNITION, DOUBLE-SIDED 1
46 21611 SCREW THP 1/4-20 X 5/8 SS 4
47 0948 WASHER, FLAT SAE 1/4 4
48 29761 MOUNTING PLATE, CONTROL PANEL 1
49 29675 WIRING KIT, DLT FOR BALLAST 1
50@ M1000120AC5M BALLAST/TRANSFORMER 60HZ 4
51 19229 BALLAST/CAPACITOR, M47 60HZ ..............................................4 ............. INCLUDES ITEMS W/@
52 GECAP35MF EXCITATION CAPACITOR 35 µF @425V .....................................1 ............. S/N 902148 AND BELOW
53 GECAP18MF EXCITATION CAPACITOR 18 µF @425V .....................................2 ............. S/N 902148 AND BELOW
