LT12 SerieS LigHT TOWer • parTS manuaL — rev. #17 (06/03/11) — page 31
nO. parT nO. parT name QTY. remarkS
1% 20S-REF-1 REF1000 BODY ASSY. 1
2% 30M-REF-REF REFLECTOR, ALUMINUM
14-7/8 X 16-5/8 IN. 1
3% 190ZQREF REF 1000 LENS 190ZQREF 1
4% 170M-REF-5 REF LENS HOLD DOWN 2
5% 70Z-FSCR3 SCREW 8-32 X 1/2 IN. 8
6% 250-REF-6 YOKE, LIGHT FIXTURE 1
7% 260Z-FSCR9 BOLT, HEX HEAD 1/2-13 x 1-1/2 IN. 2
8% 280Z-FWFL2 WASHER, FLAT 1/2 IN. 4
9% 270Z-FNT4 NUT, HEX 1/2-13 IN. 2
10% Z-C-239 VAPORTITE OCTAGON BOX 1/2 IN.
W/4 THREADED PLUGS G9 SILVER ................... 1 ..............NEW STYLE
11% 150Z-FSR3 STRAIN RELIEF SRW 1/2 IN. BLACK ................... 1 ..............NEW STYLE
12% Z-FSCR9 BOLT, HEX HEAD ZINC PLATED
1/2-13 X 1-1/2 IN. 2
15% 90Z-G-102 GASKET, HEX #5 OR #6 1
16% 70Z-SK65 MOGUL SOCKET
W/ANTI-VIBRATION GASKET 1
17% MVR1000BT37 BULB, LIGHT FIXTURE 1
18% 50Z-D-REF-SUP SUPPORT, REF1000 LAMP TIP 1
19% 230Z-FNTL6-1 KEEP NUT 8-32 6
21% 210S-CBL-6 CABLE ASSEMBLY 1
22% 200ZG106 GASKET, U-CHANNEL REFLECTOR 200ZG106 1
23 29773 LIGHT FIXTURE ASSY. ......................................... 1 ..............INCLUDES ITEMS W/%
24% 150Z-EZ67 POWER CORD, 60" W/ 3-PIN MALE PLUG .......... 1 ..............NEW STYLE
25 130Z-E76 CONDUIT BODY, 1/2 IN. HUB ................................ 1 ..............OLD STYLE
26 100Z-C-93 FLANGE, #5 OR #6 ............................................... 1 ..............OLD STYLE
27 110Z-C-91 NUT, CAST #5 OR #6 ............................................ 1 ..............OLD STYLE
28 160Z-FSR3 FITTING, CONDUIT BODY 1/2 IN. ......................... 1 ..............OLD STYLE
29 150Z-E266 CORD SET, 36 IN. W/3-PIN MALE PLUG .............. 1 ..............OLD STYLE
30 4106781000 SCREW, 8-32 X 3/8 2
laMP assY. (s/n 901682 anD aBOvE)
