LT12 SerieS LigHT TOWer • parTS manuaL — rev. #17 (06/03/11) — page 29
laMP assY. (s/n 901681 anD BElOW)
nO. parT nO. parT name QTY. remarkS
1% 43007020200 CLAMP, LIGHT ....................................................... 4 ..............REPLACES 64167441
2% 2450108 LENS GASKET ...................................................... 4 .............REPLACES 64167100
3% 5550079 LENS AND GASKET .............................................. 4 ..............REPLACES 64167744
4% 29560 SUPPORT, TOP LAMP 1000 WATT ....................... 4 ..............REPLACES 19823
5% M1000U BULB 4
6% 4101024 REINFORCING RING 1
7% 4105012 REFLECTOR (WITHOUT GLASS) 4
8% A4605079 SOCKET W/LEADS ............................................... 4 ..............REPLACES A4605079
9% 70463 SCREW, 10-24 X 5/8 BLACK 16
10% 2450120 GASKET, HOUSING/REFLECTOR 4
11% 3100056 FIXTURE HOUSING 4
12% 29169 CORD SET MOLDED 4
13% 4110624000 WASHER, 1/2 EXT. TOOTH SS 4
14% 6900446 SEAL RING .755 ID 4
15% 6900447 STRAIN RELIEF 4
17% 4101021 TRUNION (YOKE) 4
18% 63960 SCREW, HHCS 1/2-13 X 1-1/4 4
19% 29162 WASHER, LOCK HS 1/2 SS 4
20% 19695 CONNECTOR, STRAIN RELIEF 5/8-3/4 ............... 4 ..............T&B 2535
21% 4107742000 SCREW, 6-32 X 3/8 4
22% 2856 TERMINAL, SPADE 16-14#8 INSUL. ..................... 4 ..............REPLACES 1272
23% 19688 INSULATOR, SPLICE CAP (PLASTIC) 4
24% CONNECTION BOX ............................................... 4 ..............NO LONGER AVAILABLE
25% 2450121 O-RING .206" X 1.03" SILICON 4
26% 6351110 WASHER, 1/4 X 1-1/4 OD X .63 GALV. 4
27% 6301045 SCREW, 1/4-20 X 2" PH PH SS 4
28% 2450119 O-RING, 1.925" ID X 1.03" 4
29% 4106781000 SCREW, 8-32 X 3/8 PH PH 8
30% 4104021000 POP RIVET 1/8 X 3/16 DOMED AL 8
31% 4101023 BRACKET, SOCKET 4
32 29174 LIGHT FIXTURE ASSY. ......................................... 1 ..............INCLUDES ITEMS W/%
33% 29174HANDLE HANDLE, FLOODLIGHT 4
