ION 7500 / ION 7600 User’s Guide
Using the Modbus RTU Protocol
Chapter 3 - Default Meter Functionality
Page 75
Measurement
Label
Source ION Module
Modbus Module and Input Number
Modbus Register
EN50160 parameters
– refer to Appendix A for
more information about
EN50160.
V1-Dip N33
Bin
Modbus Slave #8 – Source Input #1
41048
V1-Dip N34
Bin
Modbus Slave #8 – Source Input #2
41049
V1-Dip N41
Bin
Modbus Slave #8 – Source Input #3
41050
V1-Dip N42
Bin
Modbus Slave #8 – Source Input #4
41051
V1-Dip N43
Bin
Modbus Slave #8 – Source Input #5
41052
V1-Dip N44
Bin
Modbus Slave #8 – Source Input #6
41053
V1-Dip N51
Bin
Modbus Slave #8 – Source Input #7
41054
V1-Dip N52
Bin
Modbus Slave #8 – Source Input #8
41055
V1-Dip N53
Bin
Modbus Slave #8 – Source Input #9
41056
V1-Dip N54
Bin
Modbus Slave #8 – Source Input #10
41057
V1-Dip N61
Bin
Modbus Slave #8 – Source Input #11
41058
V1-Dip N62
Bin
Modbus Slave #8 – Source Input #12
41059
V1-Dip N63
Bin
Modbus Slave #8 – Source Input #13
41060
V1-Dip N64
Bin
Modbus Slave #8 – Source Input #14
41061
V2-Dip N11
Bin
Modbus Slave #8 – Source Input #15
41062
V2-Dip N12
Bin
Modbus Slave #8 – Source Input #16
41063
Measurement
Label
Source ION Module
Modbus Module and Input Number
Modbus Register
EN50160 parameters
– refer to Appendix A for
more information about
EN50160.
V2-Dip N13
Bin
Modbus Slave #9 – Source Input #1
41064
V2-Dip N14
Bin
Modbus Slave #9 – Source Input #2
41065
V2-Dip N21
Bin
Modbus Slave #9 – Source Input #3
41066
V2-Dip N22
Bin
Modbus Slave #9 – Source Input #4
41067
V2-Dip N23
Bin
Modbus Slave #9 – Source Input #5
41068
V2-Dip N24
Bin
Modbus Slave #9 – Source Input #6
41069
V2-Dip N31
Bin
Modbus Slave #9 – Source Input #7
41070
V2-Dip N32
Bin
Modbus Slave #9 – Source Input #8
41071
V2-Dip N33
Bin
Modbus Slave #9 – Source Input #9
41072
V2-Dip N34
Bin
Modbus Slave #9 – Source Input #10
41073
V2-Dip N41
Bin
Modbus Slave #9 – Source Input #11
41074
V2-Dip N42
Bin
Modbus Slave #9 – Source Input #12
41075
V2-Dip N43
Bin
Modbus Slave #9 – Source Input #13
41076
V2-Dip N44
Bin
Modbus Slave #9 – Source Input #14
41077
V2-Dip N51
Bin
Modbus Slave #9 – Source Input #15
41078
V2-Dip N52
Bin
Modbus Slave #9 – Source Input #16
41079
