Custom Web Pages ION 7500 / ION 7600 User’s Guide
Page 270 WebMeter Internal Web Server Feature Technical Note
3. To view a custom page in HTML, click its link at the left side of the screen, or
enter the address of the page and use the .html extension.
For example:
http://10.1.50.42/webpage1.html
4. To view a custom page in XML, enter the address of the page and use the .xml
extension.
For example:
http://10.1.50.42/webpage1.xml
5. To view the meter’s catalog XML web page, enter the following address:
http:///catalog.xml
N OTE
For comprehensive information on the XML schemas provided by the Web Page module (specific to the
catalog web page), you can view the Resource Directory Description Language (RDDL) documents at:
http://rddl.xmlinside.net/PowerMeasurement/data/ion/presentvalue/catalog/1
See the online ION Programmer’s Reference for more information on using the Web
Page module.
