Using the Modbus RTU Protocol
ION 7500 / ION 7600 User’s Guide
Page 74
Chapter 3 - Default Meter Functionality
Measurement
Label
Source ION Module
Modbus Module and Input Number
Modbus Register
EN50160 parameters
– refer to Appendix A
for more information
about EN50160.
Vunbal N1
Signal Limit Evaluation
Modbus Slave #6 – Source Input #1
41016
V1-Msignal N
Mains Signaling Evaluation
Modbus Slave #6 – Source Input #2
41017
V1-Msignal N1
Mains Signaling Evaluation
Modbus Slave #6 – Source Input #3
41018
V2-Msignal N
Mains Signaling Evaluation
Modbus Slave #6 – Source Input #4
41019
V2-Msignal N1
Mains Signaling Evaluation
Modbus Slave #6 – Source Input #5
41020
V3-Msignal N
Mains Signaling Evaluation
Modbus Slave #6 – Source Input #6
41021
V3-Msignal N1
Mains Signaling Evaluation
Modbus Slave #6 – Source Input #7
41022
V1-Hrm N
Harmonics Evaluation
Modbus Slave #6 – Source Input #8
41023
V1-Hrm N1
Harmonics Evaluation
Modbus Slave #6 – Source Input #9
41024
V1-Hrm N2
Harmonics Evaluation
Modbus Slave #6 – Source Input #10
41025
V2-Hrm N
Harmonics Evaluation
Modbus Slave #6 – Source Input #11
41026
V2-Hrm N1
Harmonics Evaluation
Modbus Slave #6 – Source Input #12
41027
V2-Hrm N2
Harmonics Evaluation
Modbus Slave #6 – Source Input #13
41028
V3-Hrm N
Harmonics Evaluation
Modbus Slave #6 – Source Input #14
41029
V3-Hrm N1
Harmonics Evaluation
Modbus Slave #6 – Source Input #15
41030
V3-Hrm N2
Harmonics Evaluation
Modbus Slave #6 – Source Input #16
41031
Measurement
Label
Source ION Module
Modbus Module and Input Number
Modbus Register
EN50160 parameters
– refer to Appendix A
for more information
about EN50160.
V1-Inthrm N
Harmonics Evaluation
Modbus Slave #7 – Source Input #1
41032
V1-Inthrm N1
Harmonics Evaluation
Modbus Slave #7 – Source Input #2
41033
V2-Inthrm N
Harmonics Evaluation
Modbus Slave #7 – Source Input #3
41034
V2-Inthrm N1
Harmonics Evaluation
Modbus Slave #7 – Source Input #4
41035
V3-Inthrm N
Harmonics Evaluation
Modbus Slave #7 – Source Input #5
41036
V3-Inthrm N1
Harmonics Evaluation
Modbus Slave #7 – Source Input #6
41037
V1-Dip N11
Bin
Modbus Slave #7 – Source Input #7
41038
V1-Dip N12
Bin
Modbus Slave #7 – Source Input #8
41039
V1-Dip N13
Bin
Modbus Slave #7 – Source Input #9
41040
V1-Dip N14
Bin
Modbus Slave #7 – Source Input #10
41041
V1-Dip N21
Bin
Modbus Slave #7 – Source Input #11
41042
V1-Dip N22
Bin
Modbus Slave #7 – Source Input #12
41043
V1-Dip N23
Bin
Modbus Slave #7 – Source Input #13
41044
V1-Dip N24
Bin
Modbus Slave #7 – Source Input #14
41045
V1-Dip N31
Bin
Modbus Slave #7 – Source Input #15
41046
V1-Dip N32
Bin
Modbus Slave #7 – Source Input #16
41047
