Model G0704 (Mfg. Since 08/11)
-51-
REF PART # DESCRIPTION REF PART # DESCRIPTION
201 P0704201 QUILL RETANING CLIP 238 P0704238 MILL HEAD CASTING
202 P0704202 BUSHING 239 P0704239 COVER PLATE
203 P0704203 COMPRESSION SPRING 240 PCAP18M CAP SCREW M4-.7 X 8
204 PR56M EXT RETAINING RING 45MM 241 P0704241 FINE FEED KNOB
205 P6209ZZ BALL BEARING 6209ZZ 242 PSS26M FRONT COVER
206 P0704206 GEARS 60/70T 243 P0704243 COLLAR INDICATOR
206-1 P0704206-1 SPINDLE RING 16MM 244 P0704244 FINE FEED COLLAR
206-2 PCAP80M CAP SCREW M3-.5 X 8 245 P0704245 WORM SHAFT
207 P7007-OPEN BALL BEARING 7007-OPEN 246V2 P0704246 SPINDLE V2.08.11
208 PR05M EXT RETAINING RING 15MM 246-1 P0704246-1 DRAWBAR
209 P0704209 GEAR 37T 246-2 P0704246-2 RETAINER CUP
209-1 P0704209-1 GUARD 247 P0704247 SPINDLE RING
209-2 PCAP57M CAP SCREW M3-.5 X 6 248 P32005 TAPERED ROLLER BEARING 32005
210 PR37M EXT RETAINING RING 32MM 249 P0704249 QUILL SLEEVE
211 P6002ZZ BALL BEARING 6002ZZ 250 P0704250 RUBBER RING
212 P0704212 GEAR 42/62T 251 P0704251 ADJUSTER NUT
213 P0704213 SHAFT 252 P0704252 ADJUSTER NUT SCREW
214 PK36M KEY 5 X 5 X 50 254 P0704254 PIN 6 X 30
215 PK10M KEY 5 X 5 X 12 255 P0704255 HANDLE
216 P0704216 FORK 255-1 P0704255-1 HANDLE GRIP
217 P0704217 FORK ARM 256 P0704256 SELECTOR KNOB
218 PSS31M SET SCREW M5-.8 X 8 257 P0704257 DOWNFEED HUB
219 P0704219 DRAWBAR CAP 258 P0704258 DOWNFEED COLLAR
220 P0704220 MOTOR COVER 259 P0704259 COMPRESSION SPRING
221 P0704221 MOTOR 110V 1HP 1-PH 260 PCAP46M CAP SCREW M4-.7 X 40
221-1 P0704221-1 BRUSH ASSEMBLY 261 P0704261 DOWNFEED FLANGE
221-2 P0704221-2 BRUSH CAP 262 P0704262 SPACER
222 PW05M FLAT WASHER 4MM 263 P0704263 WORM GEAR
223 PCAP18M CAP SCREW M4-.7 X 8 264 PK69M KEY 4 X 4 X 12
224 PCAP27M CAP SCREW M6-1 X 14 265 P0704265 GEAR SHAFT
225 P0704225 SENSOR BRACKET 266 P0704266 RIVET
225-1 P0704225-1 SENSOR CORD 267 P0704267 HIGH/LOW ARROW PLATE
225-2 PCAP57M CAP SCREW M3-.5 X 6 268 PSS20M SET SCREW M8-1.25 X 8
226 P0704226 RPM SENSOR 269 P0704269 COMPRESSION SPRING
227 P0704227 MOTOR PLATE 270 PSTB004M STEEL BALL 6.5MM
228 PCAP33M CAP SCREW M5-.8 X 12 271 P0704271 SPEED SELECTOR KNOB
229 P0704229 MOTOR GEAR RING 272 PSS34M SET SCREW M5-.8 X 16
230 P0704230 GEAR 25T 273 P0704273 SPEED KNOB PLATE
231 PK72M KEY 4 X 4 X 6 274 P0704274 FORK SHAFT FLANGE
232 PSS26M SET SCREW M5-.8 X 6 275 P0704275 FORK SHAFT
233 PCAP57M CAP SCREW M3-.5 X 6 276 PCAP158M CAP SCREW M3-.5 X 16
234 P0704234 DIGITAL READOUT UNIT 292 P0704292 SPINDLE PIN
234-1 P0704234-1 DIGITAL READOUT BRACKET 293 P0704293 ARBOR R8 X B16
234-2 PCAP17M CAP SCREW M4-.7 X 10 294 P0704294 DRILL CHUCK B16 3-16MM
235 P0704235 BASE BLOCK 295 P0704295 CHUCK KEY FOR B16 16MM CHUCK
236 P0704236 QUILL LOCKING LEVER 296 P32007 TAPERED ROLLER BEARING 32007
237 P0704237 BRASS PIN
Headstock parts List
