Identification – Grizzly G0704 User Manual
Page 5

Model G0704 (Mfg. Since 08/11)
-3-
Identification
figure 1. g0704 identification.
A. drawbar Cap and drawbar
b. vertical (z-axis) handwheel
c. speed range selector Knob
D. vertical travel lock
E. Fine Feed lock Knob
f. Quill Feed lever
G. table
H. longitudinal (X-axis) handwheel
I. longitudinal table stop
J. table Cross travel locks
K. table longitudinal travel lock
L. table Center stop
M. machine stand
N. storage access door
O. Cross (y-axis) handwheel
p. longitudinal scale
Q. drill Chuck
R. headstock tilt scale
S. Chip guard
T. Quill lock lever
u. Fine Feed Knob
v. digital readout (page 4)
W. Control panel (page 4)
X. headstock
y. Column
h
h
a
b
r
s
p
o
n
i
i
l
J
m
W
X
y
v
u
g
F
d
d
C
e
K
K
t
Q
