IEI® Technology, Corp.
KINO-LX Motherboard
Clear CMOS DESCRIPTION
Short 1 - 2 (Default) Keep CMOS Setup
Short 2 - 3 Clear CMOS Setup
Table 4-3: Clear CMOS Jumper Settings
4.6.2 LCD Voltage Select Jumper
WARNING:
Making the wrong setting on this jumper may cause irreparable damage to
both the motherboard and the LCD screen connected to the on-board
connector.
Jumper Label: JP3
Jumper Type: 3-pin header
Jumper Settings: See Table 4-4
Jumper Location: See Figure 4-3
This jumper allows the user to set the voltage for the LCD panel. Before setting this jumper
please refer to the LCD panel user guide to determine the required voltage. After the
required voltage is known, make the necessary jumper setting in accordance with the
settings shown in Table 4-4.
JP3 DESCRIPTION
Short 1-2 (Default) Panel Voltage select 3V
Short 2-3 Panel Voltage select 5V
Table 4-4: LCD Voltage Setup Jumper Settings
