GarrettCom TF14 User Manual
Page 5
Magnum “14” 10Mb Media Converters
Installation and User Guide (04/01)
iv
w w w G arrettC om com
.
.
TABLE OF CONTENTS
Page
1.0 SPECIFICATIONS ................................................................................................. 1
1.1. Technical Specifications ............................................................................... 1
1.2. Summary of models and descriptions ............................................................ 7
2.0 INTRODUCTION ................................................................................................... 8
2.1 Inspecting the Package and the Product.......................................................... 8
2.2 Product Description ....................................................................................... 9
2.3 Features and Benefits ................................................................................... 13
2.4 Applications for TF14 (fiber-series) and TB14 (BNC)................................. 15
2.5 Full-duplex twisted-pair to fiber applications ............................................ 18
2.6 Link Pass-through option, applications for the TF14-LP.............................. 18
3.0 INSTALLATION .................................................................................................. 21
3.1 Locating the Media Converter Unit ............................................................ 21
3.2 TF14-series (fiber units) Power Supply Installation ..................................... 24
3.3 TB14 (BNC) Power Supply Installation ....................................................... 24
3.4 Rack Mount Tray option for TF14’s and TB14’s ........................................ 26
3.5 Calculating Overall Segment Distances ........................................................ 28
3.6 Connecting Ethernet Media .......................................................................... 31
