Magnum “14” 10Mb Media Converters
Installation and User Guide (04/01)
23
w w w G arrettC om com
.
.
TB14 END VIEW
BNC PORT
TERMINATOR
SWITCH
UPLINK
SWITCH
RJ-45
PORT
9V POWER
SUPPLY
FIBER ST
PORT
TF14 END VIEW
TB14 END VIEW
UPLINK
SWITCH
RJ-45
PORT
12V POWER
SUPPLY
TF14 END VIEW
