Where Y = The segment length on the other side of the Magnum Media Converter
divided by the Standard Maximum Media Distance for that media cabling type, x 100%
Notes: 1) Media distance calculation is the same for both half and full duplex media
converters. 2) Single-mode fiber distances more than about 4Km will exceed the 10Mb
collision domain limits, and should be operated at either full-duplex or with light traffic.
Po
l
GARRETT
Magnum TB14
Media Converter
Col RX Col RX Po
l
Li
nk Pw
r
Ja
b
TWISTED PAIR COAX
U P LINK
INT
E XT
Segment Y
55m (165 ft)
ThinNet-BNC
(10BASE-2)
Twisted Pair
(10BASE-T)
Segment X
72m (216 ft)
