Magnum “14” 10Mb Media Converters
Installation and User Guide (04/01)
35
w w w G arrettC om com
.
.
The following data has been collected from component manufacturer’s (HP’s and
Siemens’) web sites and catalogs to provide guidance to network designers and installers.
Fiber
Port
Module
Speed,
Std.
Mode
Std. km
fdx
(hdx)
Wave
-
length
nm
Cable
Size
µµµµ
m
X’mitr
Output
P
T ,
dB
R’cvr
Sens.
P
R
,
dB
Worst
OPB,
dB
Worst*
distance
Km, fdx
typical
OPB,
dB
typical*
distance
Km, fdx
FPM10-
MST, MSC
10 Mb
FL
Multi-
mode
2
(2)
850
62.5/125
100/140
50/125
-15.0
-9.5
-19.5
-31
-31
-31
14
19.5
9.5
5
5.9
3.4
17
23.5
13.5
6
7
4.8
FPM10-
SST, SSC
10 Mb
FL
Single-
mode
10
(5)
1300
9/125
-30
-39
7
14
13
26
3.6.4
Connecting ThinNet 10BASE2
Connect the ThinNet coax cable to the BNC connector on the TB14 Media
Converter in the same manner as is done for any standard BNC connection. Be sure that
the BNC segment is properly terminated using a standard “T” connector and terminator.
