Magnum “14” 10Mb Media Converters
Installation and User Guide (04/01)
7
w w w G arrettC om com
.
.
1.2 Summary of models and descriptions:
FIBER:
Magnum TF-14-d = TP to fiber, transparent hdx/fdx, ST connector, multi-mode, 115V 60Hz AC
Magnum TF-14-i = TP to fiber, transparent hdx/fdx, ST connector, multi-mode, 230V 50Hz AC
Magnum TF-14s-d = TP to fiber, transparent hdx/fdx, ST connector, single-mode, 115V 60Hz AC
Magnum TF-14s-i = TP to fiber, transparent hdx/fdx, ST connector, single-mode, 230V 50Hz AC
Magnum TF-14LP-d = TP to fiber, transparent hdx/fdx, ST, multi-mode, Link Pass-through, 115V
60Hz AC
Magnum TF-14LP-i = TP to fiber, transparent hdx/fdx, ST, multi-mode, Link Pass-through , 230V
50Hz AC
BNC:
Magnum TB-14-d = TP to BNC, half-duplex, 115V 60Hz AC power supply
Magnum TB-14-i = TP to BNC, half-duplex, 230V 50Hz AC power supply
MC14-TRAY = 19” Rack-mount tray for 14-series Media Converters, up to 16 units
