information.) If this does not help, ensure that the cable is connected properly at
both ends and is not defective.
4. For the TF14-LP model with the Link-Pass-through feature, The two LINK LEDs
operate together, and either both LEDs are lit or neither is lit. Both of the
attached cables must be operable for LINK to be indicated. Absence of LINK
does not point to the problem cable segment, and the fault may be in either.
3.6.2
Connecting Fiber Optic multi-mode, single mode (half- and full-duplex)
The following procedure applies to 10BASE-FL multi-mode and single mode
applications using the TF14, TF14s, TF14SC, and TF14-LP Media Converters. All have
ST-type fiber connectors, except the TF14SC which has SC-type connectors. The
TF14s single-mode differs from the other fiber media converters in terms of the
maximum distance allowed. The others are used for a multi-mode fiber segment lengths
of up to 2km. The TF14s is used for single-mode fiber segments of up to 10km in length.
The following table (continued next page) is provided for general information:
Fiber Cable Type
cable diameter *
Max. length Wavelength
Multi-mode fiber
50/125, 62.5/125.
2km
850 nm
