Magnum “14” 10Mb Media Converters Installation and User Guide (04/01)
37
w w w G arrettC om com . .
PWR Illuminates GREEN to indicate the unit is receiving DC power.
LINK (per port) Illuminates to indicate proper connectivity on each cable
segment (non-Link Pass-through models). LINK will turn off in
the event connectivity is lost between the ends of each cable
segment or a loss of power occurs in the unit or in the attached
device. For Link Pass-through models, see Section 3.3.3 #6.
RX (per port) Illuminates GREEN to indicate data is being received.
4.3 Front Panel LEDs - - Magnum TB14
LED Description
PWR
Illuminates GREEN to indicate the unit is receiving DC power.
LINK (TP) Illuminates GREEN, to indicate proper connectivity on the
10BASE-T network segment. LINK will turn off in the event connectivity is
lost between the ends of the twisted pair segment or a loss of power occurs in
the unit or remote device.
RX (per port) Illuminates GREEN to indicate data is being received.
POL (TP) Illuminates AMBER to indicate inverse polarity detected.
