50
Chapter 3: Using the Powerline Adapter Configuration Utility
www.gateway.com
Running a performance analysis
To run a performance analysis on the networked
Power Line devices:
1 Click Start , Programs , Gateway Powerline Adapter , then click
PLU-300 or PLE-310 . The Gateway Powerline Adapter
Configuration Utility starts and the utility scans the
Powerline network for Powerline devices that are
connected to the network.
2 Click Refresh . The utility runs an analysis on the
networked Powerline devices’ performance. The progress
bar changes to a Link Quality status bar and indicates the
average network data rate. The color of the status bar
reflects the average performance of the Powerline
network:
■ Green = Excellent
■ Yellow = Fair
■ Red = Poor
