Cpc060, Roduct, Pecifications – Goodman Mfg SS-CPC36-72 User Manual
Page 6: Cont
6
www.goodmanmfg.com
SS-CPC36-72
SS-CPC36-72
www.goodmanmfg.com
7
P
roduct
S
PecificationS
P
roduct
S
PecificationS
p
rodUCt
s
peCifiCations
— CpC060 (
Cont
.)
CPC060
***3B***C*
CPC060
***4B***B*
CPC060
***4B***C*
CPC060
***7B***B*
CPC060
***7B***C*
Cooling Capacity
Total BTU/h
58,000
59,500
58,000
59,500
58,000
Sensible BTU/h
42,800
43,200
42,800
43,200
42,800
SEER / EER
13 / 11.1
13 / 11.0
13 / 11.1
13 / 11.0
13 / 11.1
Decibels
78
78
78
78
78
ARI Reference #s
5368222
4385058
5368223
4397606
5368224
Evaporator Motor / Coil
Motor Type
Belt
Belt
Belt
Belt
Belt
Indoor Nominal CFM
2,000
2,000
2,000
2,000
2,000
Expansion Device
Piston
Piston
Piston
Piston
Piston
Piston Size (Cooling)
0.086
0.086
0.086
0.082
0.086
Filter Size (")
(4) 14 x 20 x 2
(4) 14 x 20 x 2
(4) 14 x 20 x 2
(4) 14 x 20 x 2
(4) 14 x 20 x 2
Drain Size (NPT)
¾"
¾"
¾"
¾"
¾"
R-410A Refrigerant Charge (oz.)
100.8
162
100.8
162
100.8
Face Area (ft²)
7.8
7.8
7.8
7.8
7.8
Rows Deep/ Fins per Inch
4 / 16
4 / 16
4 / 16
4 / 16
4 / 16
Tube Diameter - Material
5/16 - Copper
5/16 - Copper
5/16 - Copper
5/16 - Copper
5/16 - Copper
Evaporator Fan
Standard Belt Drive (D x W) HP
(11" X 10") 1
(11" X 10") 1
(11" X 10") 1
(11" X 10") 1½
(11" X 10") 1½
High-Static Belt Drive (D x W) HP
(11" X 10") 1½
(11" X 10") 1½
(11" X 10") 1½
(11" X 10") 1½
(11" X 10") 1½
Belt Drive Evap Fan Data
# of Wheels (D x W)
1 (11" x 10")
1 (11" x 10")
1 (11" x 10")
1 (11" x 10")
1 (11" x 10")
Motor Sheave
VL44 x ⅝
VL44 x ⅝
VL44 x ⅝
VL44 x ⅝
VL44 x ⅝
Blower Sheave / Belt
AK61 x 1 / AX55
AK61 x 1 / AX55
AK61 x 1 / AX55
AK61 x 1 / AX55
AK61 x 1 / AX55
Condenser Fan / Coil
Horsepower / RPM
¼ / 1,090
¼ / 1,090
¼ / 1,090
¼ / 1,075
¼ / 1,075
Fan Diameter/ # Fan Blades
22 / 4
22 / 4
22 / 4
22 / 4
22 / 4
Outdoor Nominal CFM
3,800
3,800
3,800
3,800
3,800
Face Area (ft²)
13.0
17.0
13.0
17.0
13.0
Rows Deep/ Fins per Inch
2 / 27
2 / 18
2 / 27
2 / 18
2 / 27
Tube Diameter - Material
5MM - Copper
5/16 - Copper
5MM - Copper
5/16 - Copper
5MM - Copper
Compressor
Quantity / Stage
1 / Scroll
1 / Scroll
1 / Scroll
1 / Scroll
1 / Scroll
Type
Single
Single
Single
Single
Single
Compressor RLA / LRA
16 / 110
7.8 / 52
7.8 / 52
5.7 / 38.9
5.7 / 38.9
Electrical Data
Voltage-Phase-Frequency
208/230-3-60
460-3-60
460-3-60
575-3-60
575-3-60
Indoor Blower HP / FLA
1.0 / 3.8
1.0 / 1.9
1.0 / 1.9
1.5 / 2.3
1.5 / 2.3
Indoor Blower LRA
24
12
12
12
12
Max External Static
1.0
1.0
1.0
1.0
1.0
Outdoor Fan HP / FLA
¼ / 1.40
¼ / 0.80
¼ / 0.80
¼ / 0.60
¼ / 0.60
Min. Circuit Ampacity¹
25
12
12
10
10
Max. Overcurrent Protection (amps)²
40
20
20
15
15
Power Supply Conduit Hole
1.125"
1.125"
1.125"
1.125"
1.125"
Low-Voltage Conduit Hole
½"
½"
½"
½"
½"
Operating Weight (lbs)
570
580
570
580
570
Ship Weight (lbs)
595
605
595
605
595
¹ Wire size should be determined in accordance with National Electrical Codes. Extensive wire runs will require larger wire sizes.
² May use fuses or HACR-type circuit breakers of the same size as noted.
Notes
• Always check the S&R plate for electrical data on the unit being installed.
• When a factory-installed powered convenience outlet is installed in the equipment, the unit MCA (Min. Circuit Ampacity) will increase by 7.5A for
208/230V units, increase by 3.75A for 460V units, and by 3A for 575V units. The MOP (Max. Overcurrent Protection) device must be sized accordingly.
