4 www.goodmanmfg.com SS-CPC36-72 SS-CPC36-72 www.goodmanmfg.com 5
P
roduct
S
PecificationS
P
roduct
S
PecificationS
p
rodUCt
s
peCifiCations
— CpC060
CPC060
***1D***B*
CPC060
***1D***C*
CPC060
***3D***B*
CPC060
***3D***C*
CPC060
***3B***B*
Cooling Capacity
Total BTU/h
59,500 58,000 59,500 58,000 59,500
Sensible BTU/h 43,200 42,800 43,200 42,800 43,200
SEER / EER 13 / 11.0 13 / 11.1 13 / 11.0 13 / 11.1 13 / 11.0
Decibels 78 78 78 78 78
ARI Reference #s 4385056 5368221 4385057 5368222 4385057
Evaporator Motor / Coil
Motor Type
Direct Direct Direct Direct Belt
Indoor Nominal CFM 2,000 2,000 2,000 2,000 2,000
Expansion Device Piston Piston Piston Piston Piston
Piston Size (Cooling) 0.086 0.086 0.086 0.086 0.086
Filter Size (") (4) 14 x 20 x 2 (4) 14 x 20 x 2 (4) 14 x 20 x 2 (4) 14 x 20 x 2 (4) 14 x 20 x 2
Drain Size (NPT) ¾" ¾" ¾" ¾" ¾"
R-410A Refrigerant Charge (oz.) 162 100.8 162 100.8 162
Face Area (ft²) 7.8 7.8 7.8 7.8 7.8
Rows Deep/ Fins per Inch 4 / 16 4 / 16 4 / 16 4 / 16 4 / 16
Tube Diameter - Material 5/16 - Copper 5/16 - Copper 5/16 - Copper 5/16 - Copper 5/16 - Copper
Evaporator Fan
Standard Direct Drive (D x W) HP
(11" X 10") 1 (11" X 10") 1 (11" X 10") 1 (11" X 10") 1 ---
Standard Belt Drive (D x W) HP --- --- --- --- (11" X 10") 1
High-Static Belt Drive (D x W) HP --- --- --- --- (11" X 10") 1½
Belt Drive Evap Fan Data
# of Wheels (D x W)
--- --- --- --- 1 (11" x 10")
Motor Sheave --- --- --- --- VL44 x ⅝
Blower Sheave / Belt --- --- --- --- AK61 x 1 / AX55
Condenser Fan / Coil
Horsepower / RPM
¼ / 1,090 ¼ / 1,090 ¼ / 1,090 ¼ / 1,090 ¼ / 1,090
Fan Diameter/ # Fan Blades 22 / 4 22 / 4 22 / 4 22 / 4 22 / 4
Outdoor Nominal CFM 3,800 3,800 3,800 3,800 3,800
Face Area (ft²) 17.0 13.0 17.0 13.0 17.0
Rows Deep/ Fins per Inch 2 / 18 2 / 27 2 / 18 2 / 27 2 / 18
Tube Diameter - Material 5/16 - Copper 5MM - Copper 5/16 - Copper 5MM - Copper 5/16 - Copper
Compressor
Quantity / Stage
1 / Scroll 1 / Scroll 1 / Scroll 1 / Scroll 1 / Scroll
Type Single Single Single Single Single
Compressor RLA / LRA 26.4 / 134 26.4 / 134 16 / 110 16 / 110 16 / 110
Electrical Data
Voltage-Phase-Frequency
208/230-1-60 208/230-1-60 208/230-3-60 208/230-3-60 208/230-3-60
Indoor Blower HP / FLA 1.0 / 7.6 1.0 / 7.6 1.0 / 7.6 1.0 / 7.6 1.0 / 3.8
Indoor Blower LRA 24 24 ---- ---- 24
Max External Static 0.9 0.9 0.9 0.9 1.0
Outdoor Fan HP / FLA ¼ / 1.40 ¼ / 1.40 ¼ / 1.40 ¼ / 1.40 ¼ / 1.40
Min. Circuit Ampacity¹ 42 42 29 29 25
Max. Overcurrent Protection (amps)² 60 60 45 45 40
Power Supply Conduit Hole 1.125" 1.125" 1.125" 1.125" 1.125"
Low-Voltage Conduit Hole ½" ½" ½" ½" ½"
Operating/Shipping Weight (lbs) 580/ 605 570/ 595 580/ 605 570/ 595 580/ 605
¹ Wire size should be determined in accordance with National Electrical Codes. Extensive wire runs will require larger wire sizes.
² May use fuses or HACR-type circuit breakers of the same size as noted.
Notes
• Always check the S&R plate for electrical data on the unit being installed.
• When a factory-installed powered convenience outlet is installed in the equipment, the unit MCA (Min. Circuit Ampacity) will increase by 7.5A for
208/230V units, increase by 3.75A for 460V units, and by 3A for 575V units. The MOP (Max. Overcurrent Protection) device must be sized accordingly.
