28 www.goodmanmfg.com SS-CPC36-72 SS-CPC36-72 www.goodmanmfg.com 29
P
roduct
S
PecificationS
P
roduct
S
PecificationS
a
irflow
d
ata
— CpC060******B/C* (
Cont
.)
s
tandard
B
elt
d
rive
— h
orizontal
ESP
(" W.C.)
Turns Open
0 1 2 3 4 5
CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP
0.2 --- --- --- --- --- --- --- --- 2420 0.79 2198 0.64
0.4 --- --- --- --- 2605 1.02 2358 0.84 2133 0.67 1874 0.52
0.6 --- --- 2526 1.06 2300 0.88 2026 0.70 1806 0.55 --- ---
0.8 2529 1.15 2252 0.93 1975 0.73 1670 0.54 --- --- --- ---
1.0 2233 0.99 1943 0.78 1628 0.57 --- --- --- --- --- ---
1.2 1907 0.83 1582 0.61 --- --- --- --- --- --- --- ---
h
igh
-s
tatiC
B
elt
d
rive
— h
orizontal
ESP
(" W.C.)
Turns Open
0 1 2 3 4 5
CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP
0.6 --- --- --- --- --- --- --- --- --- --- 2323 0.92
0.8 --- --- --- --- --- --- --- --- 2315 1.00 2009 0.77
1.0 --- --- --- --- --- --- 2308 1.09 1992 0.84 1666 0.60
1.2 --- --- --- --- 2338 1.21 1992 0.92 1646 0.66 --- ---
1.4 2359 1.32 2025 1.02 1648 0.72 --- --- --- ---
1.6 2404 1.45 2056 1.13 1684 0.82 --- --- --- --- --- ---
1.8 2088 1.24 1722 0.92 --- --- --- --- --- --- --- ---
s
tandard
B
elt
d
rive
— d
own
s
hot
ESP
(" W.C.)
Turns Open
0 1 2 3 4 5
CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP
0.2 --- --- --- --- 2579 1.01 2368 0.85 2175 0.69 1961 0.55
0.4 --- --- 2513 1.05 2318 0.89 2089 0.73 1906 0.59 1666 0.44
0.6 2514 1.14 2276 0.94 2045 0.77 1797 0.60 1604 0.47 --- ---
0.8 2261 1.01 2017 0.82 1760 0.63 --- --- --- --- --- ---
1.0 1989 0.87 1730 0.68 --- --- --- --- --- --- --- ---
1.2 1695 0.72 --- --- --- --- --- --- --- --- --- ---
h
igh
-s
tatiC
B
elt
d
rive
— d
own
s
hot
ESP
(" W.C.)
Turns Open
0 1 2 3 4 5
CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP
0.6 --- --- --- --- --- --- --- --- 2331 1.01 2072 0.80
0.8 --- --- --- --- --- --- 2324 1.10 2059 0.87 1791 0.66
1.0 --- --- --- --- 2350 1.21 2058 0.95 1774 0.72 --- ---
1.2 --- --- 2367 1.33 2086 1.06 1776 0.79 --- --- --- ---
1.4 2404 1.45 2111 1.17 1805 0.89 --- --- --- --- --- ---
1.6 2136 1.28 1835 0.99 --- --- --- --- --- --- --- ---
1.8 1868 1.10 --- --- --- --- --- --- --- --- --- ---
