30 www.goodmanmfg.com SS-CPC36-72 SS-CPC36-72 www.goodmanmfg.com 31
P
roduct
S
PecificationS
P
roduct
S
PecificationS
a
irflow
d
ata
— CpC072
s
tandard
B
elt
d
rive
— h
orizontal
ESP
(In W.C.)
0 Turns 1 Turn 2 Turns 3 Turns 4 Turns 5 Turns
CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP
0.2 --- --- --- --- --- --- 2784 1.30 2582 0.83 2411 0.79
0.4 --- --- --- --- 2814 1.34 2620 1.19 2342 0.72 2105 0.66
0.6 --- --- 2665 1.34 2583 1.19 2398 1.06 2103 0.62 1902 0.57
0.8 2689 1.38 2492 1.22 2370 1.07 2142 0.91 1816 0.51 --- ---
1 2438 1.22 2275 1.09 2098 0.92 1883 0.78 --- --- --- ---
1.2 2250 1.10 1996 0.92 --- --- --- --- --- --- --- ---
s
tandard
B
elt
d
rive
— d
own
s
hot
ESP
(In W.C.)
0 Turns 1 Turn 2 Turns 3 Turns 4 Turns 5 Turns
CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP
0.2 --- --- --- --- 2771 1.27 2567 1.05 2421 0.88 2220 0.71
0.4 --- --- 2753 1.38 2573 1.15 2382 0.95 2186 0.77 1980 0.61
0.6 2655 1.42 2548 1.24 2360 1.02 2119 0.81 1934 0.65 --- ---
0.8 2470 1.30 2331 1.11 2111 0.89 1868 0.69 --- --- --- ---
1 2296 1.18 2078 0.96 1840 0.75 --- --- --- --- --- ---
1.2 2040 1.02 --- --- --- --- --- --- --- --- --- ---
h
igh
-s
tatiC
B
elt
d
rive
— h
orizontal
ESP
(In W.C.)
0 Turns 1 Turn 2 Turns 3 Turns 4 Turns 5 Turns
CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP
0.6 --- --- --- --- --- --- --- --- 2746 1.38 2515 1.12
0.8 --- --- --- --- --- --- 2721 1.47 2494 1.21 2261 0.97
1 --- --- --- --- 2689 1.56 2500 1.32 2255 1.06 1994 0.83
1.2 --- --- 2752 1.74 2473 1.40 2252 1.15 1996 0.91 --- ---
1.4 2802 1.88 2487 1.53 2286 1.27 2037 1.02 --- --- --- ---
1.6 2553 1.67 2308 1.40 1997 1.08 --- --- --- --- --- ---
1.8 2355 1.51 2014 1.19 --- --- --- --- --- --- --- ---
2 2055 1.29 --- --- --- --- --- --- --- --- --- ---
h
igh
-s
tatiC
B
elt
d
rive
— d
own
s
hot
ESP (In W.C.)
0 Turns 1 Turn 2 Turns 3 Turns 4 Turns 5 Turns
CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP
0.6 --- --- --- --- 2793 1.64 2603 1.39 2450 1.18 2270 0.97
0.8 --- --- 2903 1.87 2696 1.57 2369 1.23 2236 1.05 1987 0.82
1 2776 1.86 2682.5 1.69 2445 1.38 2196 1.12 1968 0.90 --- ---
1.2 2599 1.71 2539 1.57 2310 1.29 1932 0.96 --- --- --- ---
1.4 2424 1.57 2305 1.40 2032 1.11 --- --- --- --- --- ---
1.6 2172 1.38 2017 1.19 --- --- --- --- --- --- --- ---
1.8 1953 1.22 --- --- --- --- --- --- --- --- --- ---
