— CpC036
CPC036
***1D***B*
CPC036
***3D***B*
CPC036
***3B***B*
CPC036
***4B***B*
CPC036
***7B***B*
Cooling Capacity
Total BTU/h
34,600 34,600 34,600 34,600 34,600
Sensible BTU/h 25,600 25,600 25,600 25,600 25,600
SEER / EER 13 / 11.0 13 / 11.0 13 / 11.0 13 / 11.0 13 / 11.0
Decibels 78 78 78 78 78
ARI Reference #s 4385050 4385051 4385051 4385052 4397604
Evaporator Motor / Coil
Motor Type
Direct Drive Direct Drive Belt Drive Belt Drive Belt Drive
Indoor Nominal CFM 1,200 1,200 1,200 1,200 1,200
Motor Speed Tap (Cooling) Low Speed Low Speed --- --- ---
Indoor motor FLA (Cooling) 2.50 2.50 3.8 1.9 2.3
Horsepower - RPM ⅓ - 890 ⅓ - 890 1.0 - 1725 1.0 - 1725 1.5 - 1725
Piston Size (Cooling) 0.068 0.068 0.068 0.068 0.068
Filter Size (Qty) (1) 24" x 24" x 2" (1) 24" x 24" x 2" (1) 24" x 24" x 2" (1) 24" x 24" x 2" (1) 24" x 24" x 2"
Drain Size (NPT) ¾" ¾" ¾" ¾" ¾"
R-410A Refrigerant Charge (oz.) 83 83 83 83 125
Evaporator Coil Face Area (ft²) 5.4 5.4 5.4 5.4 5.4
Rows Deep/ Fins per Inch 3 / 16 3 / 16 3 / 16 3 / 16 3 / 16
Evaporator Fan
Standard Direct Drive (D x W) HP
(10" X 9") ½ (10" X 9") ½ --- --- ---
Standard Belt Drive (D x W) HP --- --- (11" X 10") 1 (11" X 10") 1 (11" X 10") 1½
High-Static Belt Drive (D x W) HP --- --- (11" X 10") 1½ (11" X 10") 1½ (11" X 10") 1½
# of Wheels (D x W) --- --- 1 (11" x 10") 1 (11" x 10") 1 (11" x 10")
Motor Sheave --- --- 1VL40 X ⅝ 1VL40 X ⅝ 1VL40 X ⅝
Blower Sheave / Belt --- --- AK69 x 1 / AX52 AK69 x 1 / AX52 AK69 x 1 / AX52
Condenser Fan / Coil
Quantity of Condenser Fan Motors
1 1 1 1 1
Horsepower - RPM ¼ / 1,090 ¼ / 1,090 ¼ / 1,090 ¼ - 890 ¼ - 1,075
Fan Diameter/ # Fan Blades 22 / 4 22 / 4 22 / 4 22 / 4 22 / 4
Outdoor Nominal CFM 3,800 3,800 3,800 3,800 3,800
Face Area (ft²) 17.0 17.0 17.0 17.0 13.0
Rows Deep/ Fins per Inch 1 / 24 1 / 24 1 / 24 1 / 24 2 / 16
Compressor
Quantity / Type
1 / Scroll 1 / Scroll 1 / Scroll 1 / Scroll 1 / Scroll
Stage Single Single Single Single Single
Compressor RLA / LRA 16.7 / 79.0 10.5 / 73.0 10.5 / 73.0 5.8 / 38.0 3.8 / 36.5
Electrical Data
Voltage-Phase-Frequency
208/230-1-60 208/230-3-60 208/230-3-60 460-3-60 575-3-60
Indoor Blower HP / FLA ⅓ / 2.5 ⅓ / 2.5 1 / 3.8 1 / 1.9 1.5 / 2.3
Outdoor Fan HP / FLA ¼ / 1.4 ¼ / 1.4 ¼ / 1.4 ¼ / 0.8 0.60
Total Unit Amps 20.57 14.35 15.65 8.47 6.68
Min. Circuit Ampacity¹ 25 17 18 10 8
Max. Overcurrent Protection (amps)² 40 25 25 15 15
Power Supply Conduit Hole 1.125" 1.125" 1.125" 1.125" 1.125"
Low Voltage Conduit Hole ½" ½" ½" ½" ½"
Operating Weight (lbs) 500 500 500 500 500
Ship Weight (lbs) 525 525 525 525 525
¹ Wire size should be determined in accordance with National Electrical Codes. Extensive wire runs will require larger wire sizes.
² May use fuses or HACR-type circuit breakers of the same size as noted.
Notes
• Always check the S&R plate for electrical data on the unit being installed.
• When a factory-installed powered convenience outlet is installed in the equipment, the unit MCA (Min. Circuit Ampacity) will increase by 7.5A for
208/230V units, increase by 3.75A for 460V units, and by 3A for 575V units. The MOP (Max. Overcurrent Protection) device must be sized accordingly.
