39
Step D3:
Return to page 11, Single Gate Operator Installation, and repeat Step 1 through 15 to install
the second operator. This time in Step 15, however, the closed position stop plate on the first
gate will contact the leading edge of the second gate.
Step D-4:
Turn power switch OFF. Remove the control box cover. Using a steel punch or
screwdriver, remove the thin plastic knockout in the second operator connector hole
at the bottom of the control box. Work from the inside out to prevent any
possible damage to the control board.
Step D-6:
Insert the stripped power cable wires into the appropriate
terminal on the SECOND OPERATOR terminal block.
The green wire should be inserted into the GRN terminal,
the blue wire into BLU, the orange wire into ORG, black
wire into BLK, and the red wire into the RED terminal.
Tighten the set screws against the stripped end of the
wires. A dab of petroleum jelly on each terminal will help
prevent corrosion.
Step D-5:
Insert the strain relief into the knockout hole and
finger tighten it in the control box. Insert the
stripped end of second operator cable up through
bottom of strain relief (if necessary, loosen the
strain relief). Pull approximately 4" of wire into
the control box and retighten the strain relief on
the black sheath of the power cable.
Connecting the Second Operator to the Control Board
First Operator Power Cable
Second Operator Power Cable
RED BLK ORG BLU GRN CLS EDG O PN EDG RED
G RN O RG BLU W HT
BLK ORG BLU G RN CLS ED
G
OPN EDG
LEARN
AUTO
CLOSE
INERTI A
STATU S STATUS
BATT BATT + –
OBSTR . SENS.
RCVR
R G B
ALAR M
SECO ND O PERA TOR
FIRST OPER ATOR
POWE R IN
18VAC SOLA R
~ ~ – + ACCE SSOR Y
PWR. S W. PWR. SW.
Lock Nut
Hub
Sealing Nut
Sealing Nut
Hub
Lock Nut
Strain Relief
ON
SECOND OPERATOR FIRST OPERATOR POWER IN ALARM ACCESSORY RCVR
SEQ1
SEQ2
LEARN
18VAC SOLAR
~ ~ – +
RED BLK ORG BLU GRN CLS EDG OPN EDG RED BLK BLU ORG ORG BLU WHT GRN GRN CLS EDG OPN EDG R B G
Power Cable
from First Operator
Power Cable
from Second Operator
Low Voltage Wire
from AC Transformer
REDRED BLACKBLACK ORANGEORANGE BLBL
UEUE
GREENGREEN RED BLACK ORANGE BL
UE
GREEN REDRED BLACKBLACK ORANGEORANGE BLBL
UEUE
GREENGREEN RED BLACK ORANGE BL
UE
GREEN
