GTO/PRO 2200 Dual Gate System
Second Unit Parts List
Closed Position Stop Plate
Gate Operator with 50’ Power Cable
Post Bracket
Post Pivot Brackets (2) Gate Bracket
Rear Mount
Hardware (not to scale)
Parts
Hairpin Clip (1)
1 /
2
" x 1 1 /
4
" Clevis Pin (1)
3
/
8
" x 1
1
/
2
" Bolt (1)
1
/
2
"dia x 1
7
/
16
" Metal Spacer (1)
1 1 /
4
"
dia
x 1 /
2
" Nylon Spacer (2)
1
/
2
" x 2
3
/
4
" Bolt (3)
1
/
2
" x 3
3
/
4
" Bolt (2)
1
/
2
" x 10" Carriage Bolt (2)
8" Nylon Cable Tie (14)
1 /
2
" Washer (6)
1
/
2
" Lock Nut (7)
3 /
8
" Lock Nut (1)
2" Receiver Mounting Screw (4)
