Page 19

POWER SUPPLY CORD REPLACEMENT

(See

Fig 12 131

WARNING

follow the Pressure

Relief Procedure Warning on page 17 to reduce

the risk of a fluid injection injury, splashing in the

eyes or on the skin, injury from moving parts, or

electric shock.

Use the

mm open end wrench to remove the nut

from the filter stud (310).

2. Use the 13 mm socket wrench to remove the two

screws

holding the pressure control to the

frame.

3. Remove the pressure control mounting bracket

using a Phillips screwdriver.

4. Disconnect the power supply cord wires from the

control box terminal strip

using

screwdriver.

5. Install the new power supply cord

in the

reverse order of disassembly.
Install a new plug on the other end

the cord. Be

Fig

all local codes regarding the type of

to use.

FILTER REPLACEMENT

(See Fig 12)

WARNING

Before doing this procedure, follow the Pressure

the risk of a fluid injection injury, splashing in the

Relief Procedure Warning on page 17 to reduce

eyes or on the skin, injury from moving parts, or

1. Remove the pressure control cover and screws.

Use a needle nose pliers to remove the four wires

from the filter

Use the

M8 wrench to remove the lower nut and

lockwashers

on the outside of the

pressure control box.

4. Remove the old filter and install a new one in the

reverse order of disassembly.

Fig

307-671
