BRIDGE TEST
Remove the bridge from the pressure control box and
perform this test to determine if the bridge is functional.
continuity tester, such as multi-meter set on the X1
See Bridge Rectifier Replacement, page
Use a
ohms scale
n
the bridge fails even one test,
it
must be replaced.
Eight individual checks, or tests, must be performed.
If
11 shows the position of the wires on the bridge.
Us-
ing the chart
at
the right, connect the meter wires as in-
dicated by the black dots for each test, then check the
continuity.
In Tests 1,
2
and
3,
there should be
NO
continuity.
indicated, check continuity,
the meter wire
In Tests
4,
5
and
6,
connect the and meter wires as
get
NO continuity one way, and
YES continuity the
connections and check continuity again.
You should
other way.
In Tests 7 and connect the meter wires as indicated
by
the black dots. Touch the indicated
wire to one
meter wire, and then the other.
You should get
NO
con-
tinuity one way, and
YES continuity the other way.
BRIDGE WIRES
Fig
11
