- 8 - 7VT600-RZ Series Motherboard
English
Block Diagram
CLK
GEN
HCLK+/- (100/133/166/200MHz)
CPUCLK+/- (100/133/166/200MHz)
AGPCLK (66MHz)
PCICLK (33MHz)
USBCLK (48MHz)
14.318 MHz
33 MHz
V_Link (66MHz) / GCLK (66MHz)
VIA
KT600
VIA
VT8235
CPUCLK+/- (100/133/166/200MHz)
System Bus100/133/166/200MHz
DDR RAM
HCLK+/- (100/133/166/200MHz)
GCLK(66MHz)
33 MHz
14.318 MHz
48 MHz
AGP 4X/8X
AGPCLK
(66MHz)
5 PCI
PCICLK
(33MHz)
AC97 Link
6 USB
Ports
ATA66/100/133
IDE Channels
IT8705
24 MHz
33 MHz
Game Port
Floppy
LPT Port
PS/2 KB/Mouse
2 COM
Ports
AC97
CODEC
MIC
LINE-IN
LINE-OUT
AMD-K7 TM
BIOS
66MHz V_Link
VIA
VT6103L*
RJ45*
VCLK(66MHz)
" * " Support 7VT600-RZ only.
