BIOS Setup
- 31 -
English
F
PCI1/PCI5 IRQ Assignment
8
Auto
Auto assign IRQ to PCI 1/ PCI 5. (Default value)
8
3,4,5,7,9.,10,11,12,14,15
Set 3,4,5,7,9,10,11,12,14,15 to PCI1/ PCI5.
F
PCI2 IRQ Assignment
8
Auto
Auto assign IRQ to PCI 2. (Default value)
8
3,4,5,7,9.,10,11,12,14,15
Set 3,4,5,7,9,10,11,12,14,15 to PCI2.
F
PCI3 IRQ Assignment
8
Auto
Auto assign IRQ to PCI 3. (Default value)
8
3,4,5,7,9.,10,11,12,14,15
Set 3,4,5,7,9,10,11,12,14,15 to PCI3.
F
PCI4 IRQ Assignment
8
Auto
Auto assign IRQ to PCI 4. (Default value)
8
3,4,5,7,9.,10,11,12,14,15
Set 3,4,5,7,9,10,11,12,14,15 to PCI4.
PCI Health Status
CMOS Setup Utility-Copyright (C) 1984-2003 Award Software
PC Health Status
Reset Case Open Status
[Disabled]
Case Opened
No
Vcore
1.810V
DDR Vtt
1.248V
+3.3V
3.280V
+5V
4.919V
+12V
11.968V
5VSB
5.053V
Current System Temperature
27
o
C
Current CPU Temperature
37
o
C
Current CPU FAN Speed
4687 RPM
Current SYSTEM FAN Speed
0 RPM
CPU FAN Fail Warning
[Disabled]
SYSTEM FAN Fail Warning
[Disabled]
Item Help
Menu Level
u
[Disabled]
Don't reset case
open status
[Enabled]
Clear case open
status at next boot
higf: Move
Enter: Select
+/-/PU/PD: Value
F10: Save
ESC: Exit
F1: General Help
F5: Previous Values
F6: Fail-Save Default
F7: Optimized Defaults
