1.2 Ordering Information
Magnum DS8016 Dual-Speed Stackable Hubs
Magnum DS8016-A: Dual-Speed 10/100 Stackable Hub with sixteen RJ-45ports, each
auto-sensing for 100Mb or 10Mb operation. Stackable up to three units high,
with all ports in one stack operating as two separate traffic domains, one domain
at 100Mb/s and one domain at 10Mb/s. Includes stacking cable, internal auto-
ranging power-supply, cooling fan, and metal brackets for shelf or wall
mounting.
Magnum DS8016-B: Same as Magnum DS8016-A but includes an internal switch
module that bridges the two traffic domains, filtering and selectively forwarding
packets between the 100Mb and the 10Mb domains. Stacks up to two DS8016-
A units. One DS8016-B unit stack supports all ports at 100Mb or 10Mb
communicating with each other. The internal switch has 2Mb dynamic store-
and-forward packet buffers and 8K node addresses.
Magnum DS8016-E: Same as Magnum DS8016-A but all ports operate at 100Mbps
only(not dual speed-speed). Each port will auto-negotiate with an attached
10/100device for 100Mbps speed and half-duplex mode only. May be used in
DS8016 stacks, same as Model DS8016-A.
Magnum DS8016-R: Same as Magnum DS8016-B but with all ports on the rear side
and all of the LEDs are on front panel. No stacking. Normally used with 48V
DC dual source power supply, mounted in telco racks.
RMB-23W: Set of two mounting brackets that extend a standard 19” DS8016 hub
for mounting in a 23” -wide telco rack, 1U high.
GarrettCom, Inc. reserves the right to change specifications, performance
characteristics and/or model offerings without notice.
