System board
Connectors
Processor
fan power
connector
Main power connector
Secondary IDE connector
Serial port
connector
System fan power
connectors
Auxiliary power connector
Primary IDE connector
64-bit PCI
slots
CPU power
connector
System fan
power
connectors
SATA 1 and 2
connectors
Chassis
intrusion
switch
connector
Front panel
connector
Diskette drive connector
Front panel USB
connector
System fan
power
connector
32-bit PCI
slot
System
jumpers
CPU slot
Memory slots
Battery
