308936 45
Accessories
Use Only Genuine Graco Parts and Accessories
FLUID LINE ACCESSORIES
High Pressure Ball Valves
5000 psi (350 bar, 35 MPa) Maximum Working
Pressure
For turning fluid off or on to the gun and for relieving
fluid line pressure at the pump
210657 1/2 npt(m), Viton
r seals
210658 3/8 npt(m), Viton seals
210659 3/8 x 1/4 npt(m), Viton seals
214037 1/4 npt(m), PTFE
rseals
Fluid Swivel Fitting 189018
5800 psi (400 bar, 40 MPa) Maximum Working
Pressure
Connects to gun fluid inlet fitting 188691; 1/4 npsm(m)
x 1/4 npsm(f)
GUN ACCESSORIES
Electrostatic Gun Cleaning Kit 236659
Required when using Graco Gun Washers 112634,
112635, and 112636 to clean this gun.
Extended Air Fitting 189191
Replaces the standard air fitting (item 17 in parts list)
to provide an extended handle-grip area.
Inline Fluid Filter 205265; 60 mesh
To replace the 100 mesh Filter 205264 that is included
with the gun
Electrode Replacement Kit 236001
Includes five electrodes
Snap Ring Pliers 110090
For removing the ES ON-OFF Valve Retaining Ring
(item 47 in parts list)
Brush 105749
For cleaning the gun
Grease 217115
To grease the plastic extension on the fluid tube end.
ES ON/OFF Valve Conversion Kit 223976
Converts the ES ON/OFF Valve to a constant on
setting; a ball valve is included for complete air shut-off
at the gun
Push-Pull Pattern Adjustment Valve 224720
Pattern adjustment valve that allows quick adjustment
of the air cap air between two adjustable settings
Fluid Shut-off Spring 112876
For use with fluids that require higher shut-off force.
Use in place of compression spring 112691 (item 30 in
the parts list).
Gun Hanging Bracket 235300
