48

Chapter 5: Troubleshooting and Diagnostics

www.gateway.com

02

Internal robotic command message which is received by RobTest Module. Data
byte 1 shows the command, data byte 2 means its first parameter (usually
cartridge number).

03

Indicates an error message. Errors are represented by the same codes as
described before in this interface specification. Data byte 2 is not used in this
mode.

04

Represents a motion script information. Data byte 1 points to the current script
number, data byte 2 points to the last line executed in the script. The provided
information is rather extensive and needs to be verified by the developer of the
particular script.

05

Indicates a debug output. This type can be used by a software developer to
fix special problems. Data byte 1 and data byte 2 are free for any usage and
may depend on the investigated problem. This type will only be used during
the development phase.

Type

Description
