G4000 9'' x 19'' Lathe -7-
U Un np pa ac ck kiin ng g
This Metal Lathe is shipped from the manufactur-
er in a carefully packed carton. If you discover the
machine is damaged after you’ve signed for deliv-
ery, and the truck and driver are gone, you will
need to file a freight claim with the carrier. Save
the containers and all packing materials for pos-
sible inspection by the carrier or its agent.
Without the packing materials, filing a freight
claim can be difficult. If you need assistance
determining whether you need to file a freight
claim, or with the procedure to file one, please
contact our Customer Service.
When you are completely satisfied with the con-
dition of your shipment, you should inventory its
parts.
The G4000 is a heavy machine (300 lbs. ship-
ping weight). DO NOT over-exert yourself
while unpacking or moving your machine – get
assistance. In the event that your Metal Lathe
must be moved up or down a flight of stairs, be
sure that the stairs are capable of supporting
the combined weight of people and the
machine.
S Se erriio ou us s p pe errs so on na all iin njju urry y m ma ay y
o oc cc cu urr..
P Piie ec ce e IIn nv ve en ntto orry y
The Model G4000 is, for the most part, pre-
assembled at the factory. Inside the crate you’ll
find:
• The Model G4000 Metal Lathe
• 4" 3-jaw Chuck
• 7" 4-jaw Chuck
• Face Plate
• Steady Rest
• Following Rest
• 4-Way Tool Post
• C-Type Tool Post
• Toolbox
• Metric Allen ® Wrenches
• 8-10mm Combination wrench
• Regular Screwdriver
• Phillips ® Screwdriver
• Oil can
• 30T Gear (2)
• 36T Gear
• 42T Gear
• 45T Gear
• 80T Gear (2)
• Chuck wrenches (2)
• Chuck Removal Bars (2)
• Reverse Jaws for the 3-Jaw Chuck
• Dead Centers - MT #2, MT #3
• Live Center - MT #3
In the event that any non-proprietary parts are
missing (e.g. a nut or a washer), we would be
glad to replace them, or, for the sake of expedi-
ency, replacements can be obtained at your local
hardware store.
