G4000 9'' x 19'' Lathe -9-
C Ch hu uc ck ks s
The Model G4000 Metal Lathe comes equipped
with a 4'' 3-jaw chuck (already installed), a 7'' 4-
jaw chuck and a face plate.
The 3-jaw chuck is a scroll-type chuck, meaning
that all three jaws move in unison when adjust-
ments are made. The 4-jaw chuck, on the other
hand, features independent jaws. The 4-jaw
chuck is used for square or unevenly-shaped
stock.
The 3 and 4-jaw chucks have a setscrew in the
hub of the back plate.
F Fiig gu urre e 2 2.. This setscrew
prevents the chucks from unscrewing when rotat-
ing the lathe in the reverse direction. Prior to
removing the chuck, loosen the setscrew in the
hub of the back plate.
F Fiig gu urre e 2 2.. Typical chuck mounting.
M Mo ou un nttiin ng g
This lathe model should be securely mounted to
a stand or benchtop. An accessory stand is avail-
able from Grizzly, please see our current catalog
for pricing. There are two holes at each end of the
lathe base which can be used to secure machine
to the base.
The lathe does not require a great deal of assem-
bly. This section details the installation of the var-
ious accessory holding devices. The following
section will familiarize you with the controls for
your new lathe. After you have completed both of
these sections we will do a test run of the
machine. Do not attempt a test run until you have
become familiar with both of these sections.
S SE EC CT TIIO ON N 4 4:: A AS SS SE EM MB BL LY Y & & S SE ET TU UP P
D DO O N NO OT T a atttte em mp ptt tto o s stta arrtt tth hiis s m ma ac ch hiin ne e u un nttiill
y yo ou u h ha av ve e c co om mp plle ette ed d a allll o off tth he e a as ss se em mb blly y a an nd d
c co on nttrro oll ffa am miilliia arriiz za attiio on n s stte ep ps s.. W Wh he en n p pe errffo orrm m--
iin ng g tth he e a as ss se em mb blly y s stte ep ps s,, e en ns su urre e tth ha att tth he e
s sw wiittc ch h iis s o offff a an nd d tth he e p po ow we err iis s d diis sc co on nn ne ec ctte ed d..
F Fa aiillu urre e tto o c co om mp plly y w wiitth h tth hiis s c co ou ulld d c ca au us se e
iin na ad dv ve errtte en ntt s stta arrttiin ng g o off tth he e m ma ac ch hiin ne e w wh hiic ch h
c ca an n rre es su ulltt iin n s se erriio ou us s o op pe erra atto orr iin njju urry y..
L Lu ub brriic ca attiio on n
The G4000 is shipped from the factory pre-lubri-
cated. However, it is recommended that you go
through the entire lubrication sequence before
operating the machine. Review
S Se ec cttiio on n 7 7::
M Ma aiin ntte en na an nc ce e for lubrication instructions.
L Lu ub brriic ca attiio on n m mu us stt b be e c co om mp plle ette ed d b be effo orre e y yo ou u
s stta arrtt y yo ou urr n ne ew w lla atth he e..
Setscrew
A AL LW WA AY YS S p plla ac ce e a a p piie ec ce e o off p plly yw wo oo od d o ov ve err tth he e
w wa ay ys s o off tth he e lla atth he e b be effo orre e rre em mo ov viin ng g o orr
iin ns stta alllliin ng g a a c ch hu uc ck k.. T Th hiis s h he ellp ps s iin n p prro ov viid diin ng g a a
fflla att s su urrffa ac ce e ffo orr tth he e c ch hu uc ck k tto o lla an nd d o on n,, tth he erre e--
b by y a av vo oiid diin ng g a a p po otte en nttiia all ffiin ng ge err p piin nc ch h s siittu ua a--
ttiio on n..
